ZJBENY BUD-40/2 Type II PV DC Surge Protection Device rated at 600V DC with a 40kA maximum discharge current and high-energy varistor technology. Featuring a response time below 25 ns, plug-in protection module and DIN rail mounting, it is designed for PV combiner boxes, solar inverters, controllers and PV DC cabinets.
| Specification | Details |
|---|---|
| Brand | ZJBENY |
| Model | BUD-40/2 |
| Product Type | PV DC Surge Protection Device (SPD) |
| SPD Type | Type II |
| Application | Photovoltaic Systems |
| Rated Voltage | 600V DC |
| Maximum Discharge Current | 40kA |
| Protection Technology | High Energy Varistor |
| Response Time | <25 ns |
| Design | Prewired Modular Complete Unit |
| Protection Module | Plug-in |
| Remote Signalling | FM Contact |
| Contact Type | Floating Changeover Contact |
| Mounting | DIN Rail |
| Rail Type | TH35-7.5 / DIN35 |
| Standard | EN50539-11 |
